Converts almost any brand RKP Truck into Double RKP Surf Trucks!
All of our DoubleCarve Aluminum Trucks and Adapters are manufactured from Virgin Aluminum with T6 Heat Treatment. All Plug, Regular Barrel and Conical Bushings are cast from 85a and 90a Super High Rebound (SHR) Urethane.
The secret to the Double RKP Truck geometry is the innovative design and mechanical action of the DKP Adapter Brackets. You might notice that the different colored Brackets (above) don't include any aluminum formed Pivot Pins on them. This is because Carbon Steel L Bolts, having rounded Ball Ends serve as the Pivot Pins for the Brackets. There are also other beneficial uses of the L Bolts, such as using the threaded end of the Bolts to serve as Kingpin Bolt threads. So the specially designed L Bolts serve to both pivot the DKP Bracket Assembly and also to hold the whole Double RKP Truck System together.
Notice the picture above. The Hangers of a Regular RKP truck and a Double RKP truck have been removed and set on a flat surface. The Blue Double Kingpin Adapter Bracket is seen to have an equal overall Truck height as the black painted common RKP Baseplate next to it. (See RED dashed Arrows, above.)
This demonstrates that the overall Truck Height of Double Kingpin RKP Trucks can have an equal, or even a lower ride height, than regular, single Kingpin RKP Trucks!
This low ride height is a pretty cool Double RKP Truck Feature!
10,695,654 B1
